1 #2 #3# reforming unit in aromatics Department of a Petrochemical Company
Customer Name: a Petrochemical Company
Problems existing in the project: according to UOP design, metal wound gasket has been used for the inlet and outlet pipeline flange of reforming reactor of 1 × 2 × 2 × reforming unit of a petrochemical aromatics department, and the flange port has not been insulated. After a period of operation, especially when the generation process is unstable, the temperature and pressure will fluctuate, and the inlet and outlet pipeline flange of reforming reactor installed with metal wound gasket will leak leak
Operating conditions:
Medium: hydrogen hydrocarbon
Application: inlet and outlet pipe flange of reforming reactor of 1 # 2# reforming unit in aromatics Department of a Petrochemical Company
Working temperature: 538 ℃
Working pressure: 0.84 MPa
Solution: after many technical exchanges and the evaluation of experts from aromatics department, the bmcmcmc high-performance graphite sealing gasket independently developed by BMC in Suzhou was officially installed and used during the maintenance period, and it has been running well since the successful start-up.
Product advantages:
With super leakage proof function
Safe and reliable sealing performance
Excellent thermal shock resistance
Strong resistance to alternating load
High temperature resistance
Constant sealing stress
